Marantz AMP 20 – Reference 16-Channel Home Theatre Power Amplifier

Cinema AMP 20

Reference 12-Channel 200-Watt-per-Channel Amplifier

Made at Shirakawa Audio Works, Japan

Excellence only begins with performance.

Built upon decades of rich heritage, designed with timeless style, and engineered for utmost performance, Marantz CINEMA Series Amplifiers are the foundation of the world's most demanding home theaters.

AMP 20 is a remarkably powerful 12-channel amplifier, and can be paired with AV 20 for an elite, reference-level home theater system. AMP 20 is rated at 200 watts per channel into 8 ohms and 400 watts per channel into 4 ohms, and is built on Marantz exclusive HDAM and high-efficiency low-distortion Class D amplification.

• Detailed and immersive sound transforms your home theater

• 200 watts per channel into 80 / 400 watts per channel into 4ohms

• 12 channels powers large home theaters

• Bi-amp mode drives high- and low-frequency sections of loudspeakers independently

• BTL Mode (Bridge mode) combines two channels into a single 400-watt per channel into 8ohms

• Perfect match for Marantz AV 20 preamplifier

• Balanced XL input is ideal for reducing input noise

• Porthole with analog meter measures output

• Soft side lights cast a warm glow on the front surface of the amplifier

• Elegant design matches rich, warm sound




Sound Master Tuned

Our Marantz Sound Master meticulously tuned AMP 20 for amazing performance with careful parts selection to create outstanding sound in your home.



Making sound the Marantz way is a seamless fusion of art and science, practiced by creators who balance and select components individually for their sonic qualities — they are the Sound Masters.



Timeless Style

Excellence is heard and seen. AMP 20 is meticulously crafted with authentic materials in a modern style befitting its rich heritage and stunning performance.



AMP 20 is elegantly constructed using steel and aluminum casework while the subtle texture molded into the front panel is lit by the dimmable soft glow of sidelights on either side of our iconic porthole design.



Customizable

Comprehensive connectivity options ensure AMP 20 will always deliver the perfect results to suit your home theater.



Marantz has provided a rich assortment of connections and configuration options to make AMP 20 your ideal amplifier. While each of the 12 channels can operate independently, channel pairs can also be switched into bi-amp mode for isolating frequency bands from each other or switched into BTL mode to produce up to 400 watts per channel into 8 ohms for your highest output demands.





Effortlessly Powerful

AMP 20 gives you 12 channels of commanding power in a single enclosure each rated at 200-watt-per channel to perform at extraordinarily high levels with no loss in fidelity.



Custom Class D amplification is highly efficient, and strategically incorporated whisper-quiet fans keep the unit running optimally even under highly dynamic conditions.



Complete Compatibility

Featuring the connectivity and power to match your choice of loudspeakers, processors, and rooms.



Gold-plated RCA and high-grade XLR connectors accept audio input from most surround processors. Custom Marantz SPKT-1+ binding posts are ergonomic and provide the best possible coupling to loudspeaker cables. Low-distortion, high-power output provides ample drive to virtually any loudspeaker configuration to maximize performance.



When paired with AV 20 via the included control cable, AMP 20 can be controlled using the preamplifier. When the power of the preamplifier is turned on or placed on standby, the power of this unit is turned on or placed on standby too, and when the brightness of the preamplifier’s display is adjusted, the same setting is applied to the illumination of the AMP 20.





Marantz HDAM-SA2

Typical amplifiers use typical parts. Exceptional amplifiers like AMP 20 use bespoke technologies to achieve ultimate performance. Marantz has further optimized our legendary HDAM-SA2 circuitry for use in all signal paths. HDAM-SA2’s high slew rate and low impedance maximize clarity, resolution, and tone.



Custom Class D

AMP 20 renders dynamics with lifelike impact and clarity thanks to custom Class D amplification. Channel pairs synchronize switching frequencies, heavy buss bars replace typical wiring harnesses for better current delivery, and custom curated ingredients elevate innovative engineering into the realm of rare excellence.



Isolated Power Supplies

The high-power and small-signal portions of AMP 20 have very different power supply needs. Marantz engineered a new clean and quiet linear power supply to shield the signals from each other to prevent interference and maintain Marantz warmth and detail. The new power supply features a custom toroidal transformer for the input section and small signals. The new design provides high-power output portions of the amplifier receive massive current on demand from a switch mode power supply.



Bi-Amp Mode
Many high-end loudspeakers can be driven by two amplifiers at once (known as bi-amping)—one for low frequencies and one for high frequencies. AMP 20 can pair channels into bi-amp mode to maximize performance from loudspeakers that benefit from this feature.
