Marantz AV7706 11.2 Channel 8K Surround AV Processor / Preamplifier

The Marantz AV7706 pre-amplifier features 8K HDMI passthrough, 3D audio formats, audiophile-quality music playback, multi-room HEOS® Built-in technology, and voice control.

• 11.2 channel XLR pre-out: 11.2 channel RCA pre-out
• 8K/60Hz and select 4K/120Hz* pass-through support for every entertainment need: 8 HDMI inputs (incl. 1 front) with full HDCP 2.3 support; 3 HDMI outputs (incl. Zone 2)
• With 8K/60Hz pass-through and upscaling, Dynamic HDR and Quick Media Switching (QMS), enjoy the smoothest, crystal-clear picture quality available
• With select 4K/120Hz* pass-through, Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM) and Quick Frame Transport (QFT), experience gaming thrills with amazing imaging with reduced lag and tearing
• The latest HDR format support including HDR10, HDR10+ (New in 2020), HLG, Dolby Vision, 4:4:4 color resolution and BT.2020, as well as Dynamic HDR (New in 2020) provides exceptional brightness, clarity, and contrast for miraculous picture quality
• Advanced video processing with analog to HDMI conversion; SD to HD/8K upscaling
• Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X®, DTS Virtual:XTM, IMAX® Enhanced, and Auro-3D® processing for exceptional listening in all your favorite audio styles
• eARC (Enhanced Audio Return Channel) supports the most advanced surround and object-based audio formats via single HDMI connection between AVRs and compatible TVs
• Stream music from Internet Radio, Spotify Connect, Pandora, SiriusXM, Amazon Music HD, TIDAL, Deezer and more with Bluetooth, AirPlay 2 and HEOS® Built-in
• Built-in Wi-Fi with 2.4GHz/5GHz dual band support
• Enjoy multi-room whole-home audio streaming with HEOS® Built-in technology
• Simply use your voice to control your preferred voice assistant like Amazon Alexa, Google Assistant, Apple Siri and Josh.ai
• Decodes ALAC, FLAC and WAV lossless files up to 24-bit/192-kHz; DSD 2.8MHz and 5.6MHz tracks — enjoy your music exactly as the artist intended
• Marantz proprietary HDAM circuit boards, Current Feedback circuitry, 32-bit D/A converters, and Hybrid PLL Clock Jitter Reducer for more detailed, dynamic sound
• Suite of Audyssey room correction software: Audyssey MultEQ XT32, Dynamic Volume and Dynamic EQ, LFC, and Sub EQ HT
• Third-party integration and IR remote control, RS-232C serial port, and custom install support
• Seamless out-of-the-box experience with Quick Start Guide, guided Setup Assistant, and Marantz AVR Remote App

Advanced 11.2 channel pre-amplifier

Experience a versatile home theater setup with the new Marantz AV7706 processor/pre-amplifier. Featuring 11.2 channel XLR and RCA pre-outs, the AV7706 is built with masterful-quality external power amplification for the most demanding active speakers. Enjoy the audiophile sound you expect from Marantz combined with the latest video and audio decoding, as well as voice control with your favorite voice assistants.

Sophisticated engineering

With 11.2 channel pre-outs on both conventional RCA sockets and balanced XLRs, the AV7706 is designed to work alongside high-quality external power amplifiers like the Marantz MM8077, MM7055, and MM7025.

Not only is it a superb AV processor, the AV7706 is an extraordinary analog preamplifier with an HDAM circuit board. Using Marantz-proprietary HDAMs, the preamp section of the AV7706 provides optimal channel separation, minimum crosstalk, and enhanced signal to noise ratio for precise detail resolution and stereo imaging, while the ELNA capacitators of the analog section ensure exceptional power and dynamic ability.

Advanced 8K HDMI connectivity with eARC support

The new Marantz AV7706 includes 8 HDMI inputs and 3 outputs for all your favorite sources. One dedicated 8K input supports 8K/60Hz or 4K/120Hz pass-through capability, 4:4:4 Pure Color sub-sampling, Dolby Vision, HLG, HDR10, 21:9 video, 3D, and BT.2020 pass-through while the latest HDCP 2.3 copy protection standard is supported on all HDMI inputs.

Showcasing all the latest HDMI technology and specifications, the AV7706 lets you take your home entertainment to the next level with HDR10+, Dynamic HDR, ALLM, VRR, QMS, and QFT support. The video processor can also upscale your native video source up to 8K quality. In addition, the AV7706 features HDMI eARC which supports 3D audio formats like Dolby Atmos® and DTS:X® in masterful quality from your TV source. For your convenience, your HDMI inputs automatically rename themselves with information provided by the source when available.

Full 3D audio support

Immerse yourself in multi-dimensional audio with the latest surround formats, including Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X®, DTS Virtual:X™, IMAX® Enhanced, and Auro-3D ®.

The next chapter in movie entertainment

The new AV7706 offers the highest-quality, crystal-clear viewing experience. Enjoy your movies with 8K/60Hz pass-through or upscaling, as well the latest in HDMI technology like Dynamic HDR and Quick Media Switching (QMS), which is used in movies to eliminate video delay.

Marantz HDAM and Current Feedback topology

The AV7706 features exclusive Marantz Hyper Dynamic Amplifier Module (HDAM) technology that provide ultra-fast slew rate, true wideband performance, and maximum dynamic range for optimum sound quality.

Current Feedback technology, first introduced by Marantz nearly 70 years ago, replaces voltage feedback configuration that’s typical of AV receivers and delivers wide, closed-loop bandwidth and steep slew rate for superior fidelity with wideband audio sources.

More than 60 Years of audiophile heritage

Founded in 1953, Marantz has a rich history of designing audio components embraced by music lovers and critical listeners around the world. Because Music Matters, the AV7706 continues our long tradition of delivering a best-in-class listening experience for music and cinema.

Masterful 8K HDMI technology

The new Marantz AV7706 includes eight HDMI inputs and three outputs for all your favorite sources. With one dedicated 8K HDMI input to support 8K/60Hz or 4K/120Hz pass-through capability, 4:4:4 Pure Color sub-sampling, Dolby Vision, HLG, HDR10, 21:9 video, 3D and BT.2020 pass-through and HDCP 2.3, the latest in copy protection standards, are supported on all HDMI inputs. Showcasing the latest HDMI technology and specifications, the new AV7706 lets you take your home entertainment up a notch with HDR10+, Dynamic HDR, ALLM, VRR, QMS and QFT support. The video processor is also capable of upscaling your native video source up to 8K quality.

Dolby Atmos® and Dolby Atmos Height Virtualization Technology

You can feel every dimension in Dolby Atmos®. Enjoy a 5.1 or 7.1 surround sound speaker system and four additional overhead speakers or four Dolby Atmos elevation speakers for the ultimate home theater experience — including Dolby Surround upmixer for legacy content.

For those without in-ceiling speakers, Dolby Atmos Height Virtualization Technology leverages Dolby’s deep understanding of human audio perception to create the sensation of overhead sound from listener-level speakers.

DTS:X® and DTS Virtual:X™

DTS:X® immersive audio content places sound where it would naturally occur in space, creating life-like, multi-dimensional audio. The included spatial remapping engine of DTS Neural:X™ offers improved immersion and heightened realism in all of your favourite movies. DTS Virtual:X™ provides immersive audio without height channels, creating virtual height effects in a 7.1, 5.1 or 2.1 speaker arrangement.

IMAX® Enhanced

Get the most premium at-home entertainment experience with IMAX® Enhanced — the latest technology from DTS that sets a new standard for home theatre imaging, sound, scale, and clarity. Watch clearer pictures and brighter images. Feel immersive, heart-pounding audio and experience premium content digitally remastered by IMAX.

Auro-3D® Experience

Putting you in a cocoon of life-like sound, Auro-3D® elevates the home theatre experience to amazing new levels by delivering the excitement of three-dimensional sound for music, games, broadcast, and films. The Auromatic up-mixing engine will enhance your existing audio-visual collection.

Advanced Audyssey MultEQ XT32

Equipped with the full Audyssey Platinum suite of advanced DSP algorithms, the AV7706 features Audyssey MultEQ XT32 automatic room acoustic correction. With the supplied measurement microphone, MultEQ XT32 analyzes each speaker's output (including the subwoofers) at up to 8 measurement locations and generates precision digital filters that optimize each channel for the correct frequency and time domain response.

Audyssey Dynamic Volume smooths out disruptive jumps in volume (such as TV commercials), letting you listen at lower levels while still enjoying clear dialog, music and sound. Audyssey Dynamic EQ provides full-range clarity at any listening level, and Audyssey Low Frequency Containment uses advanced psychoacoustic algorithms to deliver a full-range balance, including deep bass, without disturbing neighbors or people in other rooms of your home. Audyssey Sub EQ HT provides individual DSP tailoring of each subwoofer in a dual subwoofer setup for deeper bass with improved definition. Plus, the Audyssey MultEQ Editor app lets you view and adjust settings for detailed tuning and customize the sound more precisely to your room and tastes.

Featuring Built-in Dual Speaker Preset Memory

The new AV7706 lets you store two Audyssey profiles as well as other amplifier configurations. You can switch between the two settings on the fly, giving you freedom to tweak your listening experience for your content or listening environment

HEOS® Built-in Multi-Room Streaming

HEOS® Built-in technology lets you enjoy your music in any room of your home for a wireless, whole-home audio experience. Play the same song in every room or select a different song for each connected room — the choice is yours. Enjoy music from Spotify, Amazon Music HD, TuneIn, SoundCloud, TIDAL, Napster, Deezer or your local music file libraries. With additional HEOS components, like HEOS-capable speakers, play all your music in one room or many.

Bluetooth, Wi-Fi and AirPlay 2 Capability

A dual antenna system lets you stream the most popular music services via Bluetooth, Wi-Fi, and AirPlay 2. Listen to your playlists on Spotify, TuneIn, and more. Use AirPlay 2 to enjoy Apple music with ease.

Bluetooth Audio Transmission

Enjoy your favorite audio without waking your whole home by transmitting the audio coming from your AV Pre-Amp to your Bluetooth headphones. The AV7706 even allows you to play the audio on both Bluetooth headphones and connected speakers simultaneously. If you have a family member or a friend who is hearing impaired, we recommend this setup.

High-Resolution Audio Support

Discover the incredible fidelity of Hi-Res Audio tracks with the ability to decode up to 24-bit/192-kHz ALAC, FLAC and WAV lossless files as well as DSD 2.8MHz and 5.6MHz tracks (the audiophile format of SACD) via the front panel USB port and network sources. You can also listen to other popular file types such as MP3.

Multi-source, Multi-room

Watch a movie in one room while another family member plays a song from Spotify in a different zone without interruption. Enjoy up to a 11.2-channel surround sound in the main room and a separate source or music stream in up to two other zones. Hook up a separate stereo amp and speakers to the second and third zone pre-out.

All Zone TV Audio

Share the main zone TV audio to all of your zones without losing fully discrete multi-channel playback in the main zone. Select “Source” for the second or third zone from the AVR remote app so that main zone audio will not switch to stereo PCM.

Convenient Smart Select Functions

The included remote has Four Smart Select function buttons so you can store your preferred or frequently used settings and call them up easily on the fly — including input source, volume level, sound mode, and Audyssey configuration. With the push of a button, the AV8805A instantly configures the receiver to your desired setting at any time.
