McIntosh C22 Mk V 2-Channel Vacuum Tube Preamplifier

C22

2-Channel Vacuum Tube Preamplifier Mk V

This newest version of our C22 Vacuum Tube Preamplifier – the Mk V – is the direct successor to our highly regarded C70 Limited Edition 70th Anniversary Vacuum Tube Preamplifier, which commemorated our 70th Anniversary.

The new C22 Mk V is the latest McIntosh vacuum tube preamplifier to carry the cherished C22 model number. It has all the performance of the acclaimed C70, but with the hallowed C22 moniker and its signature glass and aluminum front panel design.

• This is the newest version of our iconic C22 Vacuum Tube Preamplifier – the Mk V. It is the latest McIntosh vacuum tube preamplifier to carry the cherished C22 model number.
• Features (1) 12AT7 and (5) 12AX7A vacuum tubes that are visible through a glass panel on the top cover.
• Inputs consist of two balanced and three unbalanced inputs, one Moving Coil and one Moving Magnet phono inputs. There are two pairs each of balanced and unbalanced outputs.
• Includes adjustable bass and treble tone controls, plus adjustable Impedance and capacitance for the phono inputs. All control operations are done via knobs and rocker switches. Modern LED indicators denote input selection and volume level.
• Our High Drive headphone amplifier is included and features our Headphone Crossfeed Director (HXD®) technology.
• Power Control can automatically turn other connected McIntosh components on and off.
• With its retro black glass and aluminum front panel design, the C22 Mk V will fit right in with McIntosh home audio systems of any era – from the 1950s to current day.
• Dimensions (W x H x D): 17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
• Weight: 25 lbs (11.3kg)

The C22 Mk V uses one 12AT7 and five 12AX7A vacuum tubes which can be seen through a glass panel located on the top of the preamp. Knobs and rocker switches operate all control functions while modern LED lights indicate input selection and volume level. The C22 Mk V has two balanced inputs, three unbalanced inputs, one Moving Coil and one Moving Magnet phono inputs, for a total of seven inputs. There are two pairs each of balanced and unbalanced output connections; the two outputs allow sending signals to two separate power amplifiers.

Bypassable bass and treble tone controls are located on the front panel and can be adjusted in 2dB increments via rotary knobs. Impedance and capacitance for the phono inputs can also be adjusted via separate rotary knobs. In addition to setting the listening level, the volume knob can also be used to adjust the relative volume balance between the left and right audio channels. The ¼” headphone jack is powered by our High Drive headphone amplifier and features our Headphone Crossfeed Director (HXD®) technology. HXD improves the sound localization for headphone listening by restoring the directionality component of the sound stage that's normally only heard from loudspeakers.

Our Power Control technology is included with four ports that can automatically turn other connected McIntosh components such as amplifiers, CD players or turntables, on and off. Data ports are also present and can control basic functions of connected McIntosh source components via the included remote control.
